PP and PE Plastic Granulators for Waste Plastic Woven Bag Recycling

Brief Introduction

Our company specializes in providing washing lines, grinding mills, dehydrators, squeezers, label removers, plastic crushers, and granulator lines, serving the plastic recycling industry for over 10 years.

Our plastic granulator is universally suitable for recycling and granulating PP and PE waste plastic woven bags. It's not picky about raw materials, boasts high efficiency, and low noise levels, making it ideal for small and medium-sized recycling companies.

Product Advantages:

Over a decade of production experience, integrating domestic and international production technologies, and a rationally designed system with a high degree of automation throughout the entire line process and stable performance.

The entire line is easy to operate, trouble-free, and intuitive, improving efficiency and reducing labor costs.

It features high throughput, smooth operation, and low noise levels. The modular design adapts to different production standards, with customized structures for different materials.

Product Description:

1. The main motor and oil pump motor are electrically interlocked, meaning the main motor cannot start unless the oil pump motor is started, and the oil pump motor cannot stop unless the main motor is stopped. 2. The main motor and feed motor are electrically interlocked. This means the feed motor cannot start unless the main motor is started, and the main motor cannot stop unless the feed motor is stopped.

3. The main motor control cabinet has overcurrent protection. In addition, it also has a mechanical protection device, typically a nylon shear pin coupling. When the designed torque is exceeded, the shear pin is cut off, and the transmission case stops operating.

4. When the die pressure exceeds the set alarm value, the material pressure alarm light illuminates and the machine automatically shuts down.

5. It is strictly forbidden to introduce any metal debris into the raw materials produced by the user.

6. It is strictly forbidden to use metal objects to clean the material at the opening of the barrel while the machine is running.

7. Regarding the installation and removal of the pressure sensor and material temperature thermocouple, if there is material in the die, it must be heated and softened before installation and removal.

8. Please use softened or distilled water for the circulating water in the cooling system of the simplified machine. 9. The screw should only be started at low speed (≤20 rpm) and idle for no more than 2 minutes. After feeding, wait for the material to be discharged from the die before gradually increasing the speed.

Specifications:

Motor power kW: 30

Number of fixed blades: 2

Number of moving blades: 9

Weight kg: 1800

Heating power kW: 80

Cutter speed rpm: 600

Screw diameter mm: 180

Screw length mm: 1900

Single screw rotation diameter mm: 30

Machine center height mm: 1500

Filter plate aperture mm: 10

Feed port diameter: 300

Production capacity kg/h: 500
