Specialized Plastic Film Crusher Anti-Winding PE PP Film Recycling Crushing Machine

As the plastic recycling industry expands rapidly worldwide, flexible plastic film waste has become one of the most troublesome recycling materials. Thin LDPE, HDPE, PP films, shopping bags and agricultural mulch films are lightweight, easy to tangle and prone to wrapping ordinary crusher rotors, leading to frequent jamming, motor burnout and low production efficiency. Our company independently developed the specialized plastic film crusher, which is exclusively optimized for film-type soft plastics, perfectly solving the long-standing pain points of film material crushing in recycling lines.

Different from general-purpose plastic crushers for rigid plastic blocks, this plastic film crusher adopts a targeted anti-winding rotor and staggered scissor blade structure. The moving and fixed blades are made of high-hardness CrMoV alloy steel, with precisely controlled 0.2–0.4mm cutting gaps. Instead of simply impacting materials, it cuts film waste through high-frequency shearing, avoiding stretching and winding of thin films on the main shaft. Even baled bundled films and slightly soil-contaminated agricultural films can be continuously fed without frequent shutdown cleaning, greatly lifting overall production capacity.

Core Product Advantages of Our Plastic Film Crusher

1. Standard Complete Electric Control Cabinet (Mandatory Configuration)

Every industrial model of our plastic film crusher is equipped with a matched independent sealed electric control cabinet as standard, complying with international plastic machinery safety standards. The built-in complete protection system includes phase loss, overload, short circuit, motor overheating protection, safety door interlock emergency stop, and automatic reverse rotation function for material jamming. Once the crushing chamber door is opened for maintenance, the machine immediately cuts off power to prevent accidental injury. The closed cabinet isolates plastic dust from electrical components, effectively avoiding short circuit and fire risks caused by floating plastic powder, realizing safe long-time unattended operation, which meets factory safety inspection and environmental assessment requirementsFANGTAI.

2. Anti-Winding Optimized Rotor Design for Film Materials

The rotor undergoes G2.5 high-standard dynamic balance calibration, with unique anti-wrap tooth layout to stop thin films from winding around the shaft. Large flywheel design boosts torque output, reducing motor load when processing thick or stacked films, lowering power consumption by 15% compared with ordinary crushers.

3. Uniform Output Size & Easy Maintenance

Replaceable screening screens with multiple aperture options control crushed flake size from 10mm to 50mm to match downstream washing and granulation processes. The blade gap is adjustable without professional tools; worn blades can be re-surfaced and reused, cutting long-term consumable costs. The machine body adopts thickened steel plate welding, shock-absorbing base to lower running noise below 80dB, meeting industrial environmental standards.

4. Customizable Production Capacity

We supply multiple models with hourly throughput ranging from 200kg to 1500kg, supporting small workshop single-unit use and large-scale full-automatic film recycling line matching. Wet crushing structures can be customized for heavily contaminated film waste.

Wide Application Scope of the Plastic Film Crusher

This dedicated plastic film crusher handles all mainstream flexible film plastic waste materials:

Agricultural plastics: greenhouse film, crop mulch film, silage wrapping film, plastic irrigation bags

Packaging waste: LDPE packaging wrap, BOPP film, industrial stretch film, food fresh-keeping film

Daily plastic products: supermarket shopping bags, garbage bags, PP woven bags, vest plastic bags

Factory leftover waste: blown film edge trimmings, plastic film defective products from extrusion workshops

Crushed film flakes can directly enter washing tanks, friction cleaning machines and plastic pelletizing extruders, forming a complete closed-loop plastic recycling production line, helping enterprises reduce waste storage space and transportation costs, and realize circular economy production.
